Corrugated Carton Digital Printing Machine Wonder WD250-8A+

Muti Pass scanning high quality digital inkjet printing machine, printing width max 2500mm, length no limit, printing speed up to 520 ㎡/h, production efficiency around 120~450 PCS/H, your best selection for small and personalized orders.

Manufacturer Wonder

Product details


  • WD250 series digital printing machine, without plate, without cleaning, using CMYK four source color printing mode, convenient, environmental protection with low carbon.
  • The Printhead temperature system, can effectively overcome the various low temperature environment.
  • Using stronger servo motor with high precision reducer, higher precision, faster speed, more stable performance.
  • Use 6 grade super high precision gear and high precision cylindrical grinding power roller, drive more accurately.
  • Strong rail beam, Mute guide rail,Printing flat error less than 0.2mm, makes the print more stable and higher accuracy.
  • New printhead cleaning mode, automatic cleaning,saving ink, printing more frequency.
  • Print on-demand without creating waste ink,thus achieving lower consumption and better environmental protection.
  • Rapid for the orders change. Lower printing cost to run from 1+ sheet. Instant service to the customer for rush orders.


Article NO. WD250-8A+
Printhead Mirco-piezo hightest printhead
Printhead quantity 8 pieces
Ink type Special water base dye ink
Color model Cyan, Magenta, Yellow, Black
Medium distance 2mm-4mm
Printing resolution ≥600*180 dpi
Printing efficiency Max 700㎡/hour
Printing format Below 2500mm*1350mm under auto feeding
Drying speed Liner-board can be dry once print out
Working environment 20ºC-25ºC Indoor,Humidity 50%-70%
Ink supply Automatic ink supply
Feeding mode Automatic feeding
Material thickness 2mm-35mm(max can be ordered to 50mm, if between 1.2mm and 2mm may need manual feeding)
Operate system Professional RIP system professional printing system Windows 7 system with 32 bit operating system or above
Power supply About 8.5 KW power:AC380±10%,50-60HZ
Machine size L*W*H:2912*4594*1622(mm)
Weight 3500KGS
