Automatic Folding Carton Gluers Ace machinery Signature Albatross

Straight line / 3 Corners / 4&6 Corners / Special

Manufacturer Ace Machinery

Product details


  • Ultimate model that jump over limit of flute and width, corrugated folder gluer "ALBATROSS"
  • ALBATROSS, corrugated folder glueris for various type flute of normal box and corrugated box. (N,F,E,B,C,AB,AC,BC,EB,EF… and from SL to 6CS)
  • Easy automatic setting and stable production with 350mpm speed is available using Auto Jog.

Please contact us for various width.


Model 220 300
Straight line cartons
B(mm) 290~2200
L(mm) 140~1600
C(mm) 130~1085
B(mm) 290~3000
L(mm) 140~1600
C(mm) 130~1470
Crash-lock bottom cartons
B(mm) 310~2100
L(mm) 190~1600
C(mm) 140~1035
B(mm) 310~2800
L(mm) 190~1600
C(mm) 140~1370
4-corner collapsible boxes
B(mm) 290~2000
L(mm) 250~1600
C(mm) 50~250
B(mm) 290~2800
L(mm) 250~1600
C(mm) 50~250
6-corner collapsible boxes
B(mm) 500~1600
L(mm) 250~1000
C(mm) 50~250
B(mm) 500~2400
L(mm) 250~1000
C(mm) 50~250
Heavy solid board(gm2) 800~2000 800~2000
Corrugated board N,F,E,B,C AB,AC BC,EB,EF Flute N,F,E,B,C AB,AC BC,EB,EF Flute
Length (m) 24.9 24.9
Weight (t) 19 24
Total connected load (kva) 95 95

Carton Aligner Section

It aligns the blank that was fed from the feeder at any speed / The Carton Alignment section is an essential option for accurate folding, gluing and braille works.


The setting time can be significantly shortened by automatic setting of carriers. It eliminates the stress and time consuming of settings and it has unlimited data space to input, store and recall setting values regardless of the size and number of workpieces.

4/6CS, 8CS Back Folding

Ace Machinery Co., Ltd. Developed with its own technology, 4/6 C/S and 8C/S servo back folding device. 50,000 sheets per hour can be produced through this device and German servo motor and drive. (World's first) / Simple operation is available just by inputting distance, angle, speed

Glue Supply Device

It does not require frequent replacement of the glue due to large storage, and the sensor does not cause a no-glue phenomenon because of the correct amount of glue supply. This reduces work time and increases productivity. You can use it cleanly without worrying about overflowing because the pump automatically feeds the glue without putting the glue directly.


It is a device that maintains the consistency of the quality of the loading and the alignment of the blank by correcting disorder and scattering of folded cartons when produce thick blanks.
